Overview
Details
Accessories
Colors & Textures
Testing & Certifications
| Characteristic | Specifications |
|---|---|
Weight Per Square
|
1650 lbs. |
Pieces Per Square
|
412 pcs. |
 Overall Size |
7" x 12" x 1/2" |
 Exposure |
7" x 5" |
 Installed Barrel Height Off Deck |
N/A |
 Recommended Minimum Slope |
5:12 |
 Base Texture |
Roughed |
| # | Document | Description | AutoCAD | |
|---|---|---|---|---|
| 1 | ANTIQUE-100 | SECTION AT EAVE | View PDF | Download AutoCAD |
| 2 | ANTIQUE-101 | SECTION AT SIDE WALL | View PDF | Download AutoCAD |
| 3 | ANTIQUE-102 | SECTION AT HEAD WALL | View PDF | Download AutoCAD |
| 4A | ANTIQUE-103 | SECTION AT CLOSED RAKE EDGE | View PDF | Download AutoCAD |
| 4B | ANTIQUE-104 | SECTION AT OPEN RAKE EDGE | View PDF | Download AutoCAD |
| 5A | ANTIQUE-200 | SECTION AT V-HIP | View PDF | Download AutoCAD |
| 5B | ANTIQUE-201 | SECTION AT #118 HIP | View PDF | Download AutoCAD |
| 5C | ANTIQUE-202 | SECTION AT BONNET HIP | View PDF | Download AutoCAD |
| 6A | ANTIQUE-300 | SECTION AT V-RIDGE | View PDF | Download AutoCAD |
| 6B | ANTIQUE-301 | SECTION AT #211 RIDGE | View PDF | Download AutoCAD |
| 6C | ANTIQUE-302 | SECTION AT #211 VENTED RIDGE | View PDF | Download AutoCAD |
| 6D | ANTIQUE-303 | SECTION AT ROUNDED INTERLOCKING RIDGE | View PDF | Download AutoCAD |
| 7 | ANTIQUE-400 | SECTION AT FIELD CUT VALLEY | View PDF | Download AutoCAD |
| # | Accessory | Description |
|---|---|---|
| 1 |  |
TerminalA tile installed at the intersection of hip(s) and ridge(s). |
| 2 |  |
Ridge TileA tile that is shaped to cover the uppermost horizontal part of the roof. |
| 3 |  |
Hip StarterA tile installed at the bottom of the hip, also known as bullnose. |
| 4 |  |
Closed Ridge EndClosed-end tile installed at the gable end of the ridge. |
| 5 |  |
Hip TileA tile that is shaped to cover the external angle formed by the intersection of 2 sloped planes. |
Colors
Ludowici’s Antique clay roof tile is available in all standard and custom matte colors developed by Ludowici.
Textures
Ludowici’s Antique clay roof tile features a roughed base texture. It is also available in the following custom texture:
Miami Dade NOA No. 23-0125.07
Download
IAPMO Evaluation Report
Download
Florida Building Code - Evaluation Report
Download
Ludowici Clay Roofing Tile - Glazed & Unglazed OSHA GHS SDS 2014
Download
Ludowici Clay Roofing Tile - Glazed & Unglazed China GHS SDS 2014
Download
Environmental Product Declaration
Download
